Expansion Cards
Description Spare part number
nVidia GeForce GT630 PCIe x16 graphics card, 2 GB (not for use with Windows 8) 684591-001
nVidia GeForce GT630 PCIe x16 graphics card, 2 GB (for use with Windows 8) 702084-001
nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB 680653-001
nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB (not for use with Windows 8) 632486-001
nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB (for use with Windows 8) 700578-001
nVidia GF505 PCIe x16 graphics card, 512 MB (for use only in China) 702648-001
AMD Radeon HD7450 PCIe x16 graphics card, 1 GB (not for use with Windows 8) 682411-001
AMD Radeon HD7450 PCIe x16 graphics card, 1 GB (for Windows 8; use only in China) 702646-001
AMD Radeon HD7450 PCIe x16 graphics card, 1 GB (for Windows 8; not for China) 702647-001
AMD Radeon HD6350 PCIe x16 graphics card, 512 MB (not for use with Windows 8) 637995-001
AMD Radeon HD6350 PCIe x16 graphics card, 512 MB (for use with Windows 8) 697246-001
Intel PRO/1000CT2 NIC, includes bracket 635523-001
HP FireWire / IEEE 1394a PCIe x1 Card 637591-001
The computer has one PCI expansion slot, two PCI Express x1 expansion slots, and one PCI
Express x16 expansion slot.
NOTE: You can install a PCI Express x1, x4, x8, or x16 expansion card in the PCI Express x16 slot.
To remove, replace, or add an expansion card:
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 54)
2. Remove the access panel (
Computer Access Panel on page 55)
3. Locate the correct vacant expansion socket on the system board and the corresponding
expansion slot on the back of the computer chassis.
Expansion Cards 63
