5–48 Maintenance and Service Guide
Removal and Replacement Procedures
5.18 ExpressCard Assembly
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
2. Push in on the ExpressCard bezel 1 to release the bezel from
the ExpressCard slot.
3. Remove the ExpressCard bezel 2.
✎
The ExpressCard bezel is included in the Plastics Kit, spare
part number 431428-001.
Removing the ExpressCard Slot Bezel
ExpressCard Assembly Spare Part Number Information
ExpressCard assembly 431439-001
