5–18 Maintenance and Service Guide
Removal and Replacement Procedures
5.10 Switch Cover
1. Prepare the computer for disassembly (Section 5.3).
2. Close the computer.
3. Turn the computer upside down with the front panel
toward you.
4. Remove the three Phillips PM2.5×5.0 screws that secure the
switch cover to the computer.
Removing the Switch Cover Screws
5. Turn the computer display-side up with the front toward you.
6. Open the computer as far as possible.
Switch Cover Spare Part Number Information
For use with full-featured computer models
For use with defeatured computer models
431423-001
431422-001
