5–50 Maintenance and Service Guide
Removal and Replacement Procedures
5.19 USB/Power Connector Board
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
USB/Power Connector Board Spare Part Number Information
USB/power connector boards (include USB/power connector board cable)
For use with 90W AC adapters
For use with 65W AC adapters
431446-001
431445-001
