Screw Listing
Maintenance and Service Guide A–15
Phillips PM2.5×7.0 Screw Locations
Table A-4
Phillips PM2.5×7.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 26 7.0 mm 2.5 mm 5.0 mm
Where used:
1 One screw that secures the top cover support trim to the computer
(documented in Section 5.15)
2 Two screws that secure the top cover to the computer (documented in
Section 5.15)
mm
