Page #12 background imageLoading...
Page #12 background image
9
15
#ASSY USB BD
1
16
#ASSY Rear cover
1
17
#Spring
2
18
#Screw
2
19
#Slider
1
20
#OSD key
1
21
#OSD key BD
1
22
#Speaker cover
1
23
#HP Rear LOGO
1
24
#VESA Cosmetic cover
1
25
#Wall mount Screws
4
26
#ASSY Stand
1
27
#ASSY Base
1
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
POWER BD RB23HHC-XUS(C)E23 G4 D
M84511-001
755.06704.0001
POWER BD RB23HHC-XUL(C)E23 G4 D
M84512-001
755.06704.0002
POWER BD RB23HHC-XUE(C)E23 G4 D
M84513-001
755.06704.0003
POWER BD RB238HC-XUD(C) E24 G4 DIP
M84514-001
755.06602.0001
POWER BD RB238HC-XUU(C) E24 G4 DIP
M84515-001
755.06602.0002
POWER BD RB238HC-XUM(C) E24 G4 DIP
M84516-001
755.06602.0003
POWER BD RB238HC-XUS(C) E24 G4 DIP
M84517-001
755.06602.0004
POWER BD RB238HC-XUE(C) E24 G4 DIP
M84518-001
755.06602.0005
POWER BD RB238HC-XUL(C) E24 G4 DIP
M84519-001
755.06602.0006
Capacitors and connectors are available for purchase from the following EU distributors:
SUSCON : www.su-scon.com
CAPXON: www.capxongroup.com
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
CAP EL 470U 25V M RT5
10*16 HG
PT503,PT504,PT506
SUSCON
HG025M471G16T014P50R
CAP EL 470U 25V M RT5 10*16
FH CAPXON
CAPXON
FH471M025G160ETABZ

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E23 G4 and is the answer not in the manual?

HP E23 G4 Specifications

General IconGeneral
Color gamut72 %
Screen shapeFlat
Display diagonal23 \
Surface hardness3H
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Maximum refresh rate60 Hz
Viewable size, vertical286.4 mm
Contrast ratio (dynamic)5000000:1
Contrast ratio (typical)1000:1
Display number of colors-
Viewable size, horizontal509.1 mm
Digital vertical frequency50 - 60 Hz
Digital horizontal frequency30 - 80 kHz
Display brightness (typical)250 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Product colorBlack, Silver
Market positioningBusiness
Cables includedAC, DisplayPort, HDMI, USB, VGA
HDMI version1.4
USB hub version3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
USB upstream port typeUSB Type-B
USB Type-A downstream ports quantity4
Pivot angle-90 - 90 °
Tilt angle range-5 - 23 °
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
Energy efficiency scaleA to G
Power consumption (max)51 W
Power consumption (standby)0.5 W
Power consumption (typical)21 W
Package depth223 mm
Package width581 mm
Package height372 mm
Package weight8000 g
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)207 mm
Width (with stand)521.6 mm
Height (with stand)489.8 mm
Weight (with stand)5400 g
Depth (without stand)47 mm
Height (without stand)313.1 mm
