Power board
The power board part number is 755.09Q02.0001.
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 10.
Remove the power board:
1) The HP E24 G5 power board connector position is as follows:
CN801 Wistron P/N: 021.61323.0106
2) Locate the part number location on the board.
3) Pin solder with soldering iron and absorber.
CN801
