HP E24u G5 User Manual

9
14
#Vesa cover E24u
1
15
#ASSY Hinge E24u
1
16
#ASSY Base E24u
1
17
#ASSY Lift E24u
1
18
#ASSY function key BD E24u
1
19
#Lens E24u
1
20
#Function key E24u
1
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PWR BD RF238HC-BYDE(C) E24U G5 DIP
N43526-001
755.09S02.0001
Capacitors and connectors are available for purchase from the following EU distributors:
 CAPXON: www.capxongroup.com
Capacitors by distributor
Component description
Location
Component distributor
Distributor part number
CAP EL 470U 35V M P5 10*16 ZH
AC714, AC715, AC717
CAPXON
ZH471M035G160ETABHR
Connectors by manufacturer
Component
description
Location
identifier
Component
distributor
Distributer part number
Remark
HDMI
HDMI1
Switchcraft
Inc.
https://www.digikey.com
PN:
HD03-19-P-FR
DP
DP1
DP2
Molex
https://www.digikey.com
PN:
2041441-1
USB-C
USBC1
USBC2
CUI
Devices
https://www.digikey.com
PN:
UJ40-C-V-G-SMT-TR
RJ45
LAN1
Würth
Elektronik
https://www.digikey.com
PN:
732-3170-ND

HP E24u G5 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	Edge LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.5 cm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HP segment	Business
Product color	Black, Silver
Country of origin	China
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	3
Weight	6000 g
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	140 mm
Package width	621 mm
Package height	400 mm
Package weight	8000 g
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	160 W
Power consumption (standby)	0.5 W
Power consumption (typical)	23.5 W

Weight and Dimensions

Depth (with stand)	211 mm
Height (with stand)	507 mm
Depth (without stand)	47 mm
Width (without stand)	539.4 mm
Height (without stand)	322.6 mm
