Item Component Spare part number
(1) Display assembly (includes webcam/microphone module and wireless antenna cables):
(2) Top cover with keyboard
NOTE: For a list of country code suxes for the top cover/keyboard spare part numbers listed below, see Bottom cover
on page 35.
For use in models without ngerprint reader 812692-xx1
For use in models with a ngerprint reader 812726-xx1
(3) TouchPad assembly 818040-001
(4) Touchpad support bracket 818042-001
Power connector cable kit 812681-001
(5) Power connector bracket
(6) Power connector cable
(7) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: No-Windows operating systems
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Includes Intel Core i7-5500U processor and 4 GB of discrete graphics memory 812712-xxx
Includes Intel Core i7-5500U processor and 2 GB of discrete graphics memory 812710-xxx
Includes Intel Core i7-5500U processor and UMA graphics memory 812713-xxx
Includes Intel Core i5-5200U processor and 4 GB of discrete graphics memory 812711-xx
Includes Intel Core i5-5200U processor and 2 GB of discrete graphics memory 812709-xxx
Includes Intel Core i5-5200U processor and UMA graphics memory 837094-xxx
(8) RTC battery 819504-001
Heat sink (includes replacement thermal material):
(9a) For use in models with discrete graphics 812684-001
(9b) For use in models with UMA graphics 812683-001
Includes fan, for use in models with UMA graphics 830002-001
(10) Fan (includes cable) 812682-001
(11) RJ-45 door
For use in models without an optical drive 812701-001
For use in models with an optical drive 818652-001
(12) Solid-state drive (M.2)
256 GB 812708-001
128 GB, 2280 M.2 829985-001
128 GB (Best Buy SKUs) 820547-001
(13) WLAN module
18 Chapter 3 Illustrated parts catalog
