Solid-state drive (M.2)
Description Spare part number
256 GB solid-state drive, M.2, TLC 812708-001
128 GB, 2280 M.2 829985-001
128 GB solid-state drive, M.2, TLC (Best Buy SKUs) 820547-001
Before removing the solid-state drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 35).
5. Disconnect the battery.
Remove the solid-state drive:
1. Remove the Phillips PM2.0×3.5 screw (1) that secures the solid-state drive to the system board.
2. Remove the solid-state drive (2) by pulling the drive away from the slot at an angle.
42 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
