RJ-45 door
Description Spare part number
RJ-45 door for use in models without an optical drive 812701-001
RJ-45 door for use in models with an optical drive 818652-001
Before removing the RJ-45 door, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 35).
5. Disconnect the battery.
Remove the RJ-45 door:
1. Remove the two Phillips PM2.0×5.0 screws (1) that secure the RJ-45 door to the computer.
44 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
