TouchPad assembly
Description Spare part number
TouchPad assembly 818040-001
Touchpad support bracket 818042-001
Touchpad cable 818041-001
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 35).
5. Remove the battery (see Battery on page 54).
6. Remove the hard drive (see Hard drive on page 55).
7. Remove the speakers (see Speakers (front) on page 57).
Remove the TouchPad:
1. Disconnect the TouchPad cable from the TouchPad (1).
2. Remove the TouchPad (2) cable from the computer.
3. Remove the seven Phillips PM2.0×3.0 screws (1) that secure the TouchPad bracket to the computer.
64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
