HP ENVY User Manual

Bottom cover
In this section, the rst table provides the main spare part number for the top covers/keyboards. The second
table provides the country code suxes for the spare part number.
Description Spare part number
Bottom cover for use in models without an optical drive 812672-001
Bottom cover for use in models with an optical drive 812673-001
Top cover with keyboard for use in models without a ngerprint reader 812692-xx1
Top cover with keyboard for use in models with a ngerprint reader 812726-xx1
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
Belgium -A41 Italy -061 South Korea -AD1
Bulgaria -261 Japan -291 Spain -071
Canada -DB1 Latin America -161 Switzerland -BG1
Czech Republic
and Slovakia
-FL1 The Netherlands -B31 Taiwan -AB1
Denmark, Finland, and
Norway
-DH1 Portugal -131 Thailand -281
France -051 Romania -271 Turkey -141
Germany -041 Russia -251 United Kingdom -031
Greece -151 Saudi Arabia -171 United States -001
Hungary -211 Slovenia -BA1
Before removing the bottom cover, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
Remove the bottom cover:
1. Remove the eight Phillips PM2.5×8.0 screws that secure the bottom cover to the computer.
Component replacement procedures 35

HP ENVY Specifications

General

Bus type	DMI
Stepping	D2
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-2630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM67 Express
HDD speed	5400 RPM
HDD capacity	750 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1500 GB
Number of HDDs installed	2
Display diagonal	17.3 \
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Type	PC
Power supply type	AC/DC
Power requirements	100 - 240V
AC adapter included	Yes
Wireless technology	Wi-Fi
Graphics card family	AMD
Compliance industry standards	802.11a/b/g/n
Maximum internal memory (64-bit)	16 GB
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6850M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Keyboard layout	AZERTY
Pointing device	Touchpad + Scroll zone
Networking type	10/100/1000
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Password protection type	BIOS, HDD
Battery life (max)	2.25 h
Number of battery cells	6
AC adapter power	120 W
Sustainability certificates	EPEAT Silver
Product color	Black, Silver
Country of origin	China
Processor code	SR02Y
Processor ARK ID	52219
Processor package size	37.5 x 37.5 (rPGA998) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	275 mm
Width	416 mm
Height	38.7 mm
Weight	3410 g
