HP Integrity BL860c i4 User Manual

Step Condition Action
6d "SYSVARS_MISMATCH" - The system
variable stored on the Blade Link does not
match the system variable stored on the
blade.
Use the sysset command.
6e "SBL_DOMAIN_IMPROPER_SBL" - The
Blade Link currently installed is not
appropriate for the blade slot (even/odd)
and enclosure (c7000/c3000) being used.
1. Be sure that the Blade Link installed in the
correct slot and enclosure, see Installing the
Blade Link for BL860c i4, BL870c i4 or
BL890c i4 configurations on page 25.
2. Be sure that the Blade Link is properly
installed and fully seated.
3. Look for bent connector pins on the Blade
Link.
6f "POWER_FAIL_IMPROPER_SBL" - Power
command failed because the Blade Link
currently installed is not appropriate for
the blade slot (even/odd) and enclosure
(c7000/c3000) being used.
1. Be sure that the Blade Link installed in the
correct slot and enclosure, see Installing the
Blade Link for BL860c i4, BL870c i4 or
BL890c i4 configurations on page 25.
2. Be sure that the Blade Link is properly
installed and fully seated.
3. Look for bent connector pins on the Blade
Link.
6g Incorrect number of processors displayed
for the conjoined blades
1. Be sure that the Blade Link is properly
installed and fully seated.
2. Look for bent connector pins on the Blade
Link.
3. Check the MP logs for CPUs that were de-
configured by system firmware. The UEFI
cpuconfig command can be used to show
and re-configure hardware or software de-
configured CPUs.
6h
"QPI_CPU_LINK_DEGRADED"
Be sure that the Blade Link is properly installed
and fully seated.
90 Troubleshooting
