7-34
Configuring RADIUS Server Support for Switch Services
Configuring and Using Dynamic (RADIUS-Assigned) Access Control Lists
to create ACL support for a client having a username of “User-10” and a
password of “auth7X”. The ACL in this example must achieve the follow-
ing:
Permit http (TCP port 80) traffic from the client to the device at
10.10.10.117.
Deny http (TCP port 80) traffic from the client to all other IPv4
addresses.
Deny Telnet (TCP port 23) traffic from the client to any IPv4 address.
Permit all other IPv4 traffic from the client to all other devices.
To configure the above ACL, you would enter the username/password and
ACE information shown in figure 7-11 into the FreeRADIUS “users” file.
Figure 7-11. Example of Configuring a FreeRADIUS Server To Filter IPv4 Traffic for a Client Using the Correct
Username and Password Credentials.
User-10 Auth-Type:= Local, User-Password == auth7X
HP-Nas-Rules-IPv6 = 1,
HP-Nas-filter-Rule = “permit in tcp from any to 10.10.10.117 80”,
HP-Nas-filter-Rule += “deny in tcp from any to any 80”,
HP-Nas-filter-Rule += “deny in tcp from any to any 23”,
HP-Nas-filter-Rule += “permit in ip from any to any”
Client’s Username (802.1X or Web Authentication)
Client’s Password (802.1X or Web Authentication)
