Installing the Print Server 2-13
ENWW
HP J4167A (610N)
for Token
Ring (IEEE 802.5) networks. A
Data Rate switch selects
operation for 4-Mbps or 16-
Mbps Token Ring networks.
This card provides an RJ-45
connector for networks that use
unshielded twisted-pair cables,
and a DB 9 connector for Type
1, 2 or 6 shielded twisted-pair
cables.
You can use only one Token Ring port:
RJ-45 or DB 9.
HP J6057A (615N) or J4169A
(610N)
for Ethernet, IEEE 802.3
Type 10Base-T or IEEE 802.3u
Type 100Base-TX networks.
The card autonegotiates
operation at 10 or 100 Mbps, full-
or half-duplex mode, but can be
manually set through the
printers control panel.
This card provides a single
RJ-45 connector for networks
that use unshielded twisted-pair
cables.
To manually set link operation, see
Appendix A
.
Data Rate Switch
