Classic Control Panel
As described in Table A.1, the HP Jetdirect EIO control panel menu
allows you to enable or disable network protocols, and configure
selected network parameters. On the control panel display, an
asterisk (*) is used to identify the selected value.
Table A.1 HP Jetdirect EIO Classic Control Panel Menu (1 of 2)
Menu Item Description
CFG NETWORK=NO* Selects whether or not you want to access the
Jetdirect menu.
NO* (default): Bypass the HP Jetdirect menu.
YES*: Access the HP Jetdirect menu. You must
change this to YES* each time you want to access
the menu.
IPX/SPX=ON*
DLC/LLC=ON*
TCP/IP=ON*
ATALK=ON*
Identifies whether the protocol stack is enabled or
disabled.
ON* (default). The protocol is enabled.
OFF*: The protocol is disabled.
CFG IPX/SPX=NO* Selects whether you want to access the IPX/SPX
menu and set IPX/SPX protocol parameters.
NO* (default): Bypass the IPX/SPX menu items.
YES*: Access the IPX/SPX menu items.
In the IPX/SPX menu, you can specify the
Frame
Type
parameter used on your network.
AUTO (default) will automatically set and limit the
frame type to the first one detected.
For Ethernet cards, frame type selections include
EN_8023, EN_II, EN_8022, EN_SNAP.
For Token Ring cards, frame type selections
include TR_8022, TR_SNAP.
In the IPX/SPX menu for Token Ring cards, you
can also specify
NetWare Source Routing
parameters, which include SRC RT=AUTO
(default), OFF, SINGLE R, or ALL RT.
