IPX/SPX ENABLE ON: Enable the IPX/SPX protocol
OFF: Disable the IPX/SPX protocol
FRAME
TYPE
Selects the frame type setting for your network.
AUTO: (Default) automatically sets and limits the
frame type to the first one detected.
EN_8023, EN_II, EN_8022, EN_SNAP are frame
type selections for Ethernet networks.
TR_8022, TR_SNAP are frame type selections for
Token Ring networks.
SOURCE
ROUTING
(Token Ring only) Specify the
NetWare Source
Routing
parameter
AUTO: (Default) The type of source routing
required on the network is automatically sensed
OFF: All packets are sent without source routing,
and only packets from the same ring are received.
ALL ROUTES and SINGLE ROUTES: All packets
are sent with source routing (broadcasts, and when
the route is unknown)
ATALK ENABLE (Ethernet/Fast Ethernet only)
ON: Enable the AppleTalk protocol
OFF: Disable the AppleTalk protocol
DLC/LLC ENABLE ON: Enable the DLC/LLC protocol
OFF: Disable the DLC/LLC protocol
LINK
SPEED
Selects the network link speed and communication
mode for the 10/100TX print server. For proper
communications, the Jetdirect settings must match
the network.
AUTO: (Default) The print server will automatically
configure itself to match the network’s link speed
and communication mode.
10T HALF: 10Mbps, half-duplex operation.
10T FULL: 10 Mbps, full-duplex operation.
100T HALF: 100 Mbps, half-duplex operation
100T FULL: 100 Mbps, full-duplex operation
Table A.2 HP Jetdirect EIO Graphical Control Panel Menu (2 of 2)
