Component Identification
Table 1-8: System Board LEDs continued
Item LED Description Status
6 DIMM 1 failure
7 DIMM 2 failure
8 DIMM 3 failure
9 DIMM 4 failure
Amber = The DIMM is failed.
Off = The DIMM is functioning.
10 Processor 2 failure Amber = Processor 2 has failed or is
missing.
Off = Processor 2 is functioning.
11 System
overtemperature
Amber = The temperature threshold has
been exceeded.
Off = The temperature is normal.
12 Processor fan 2
failure
Amber = Processor fan 2 has failed or is
not installed.
Off = Processor fan 2 is functioning.
13 AC power Green = The power supply is attached to
AC power.
Off = The AC power cord is not connected
to the power supply, the power supply
connector is not attached to the system
board, or the power supply has failed.
1-12 HP ProLiant ML330 Generation 3 Server Setup and Installation Guide
