HP MSA 2050 User Manual

40 Connecting to the controller CLI port
4. Start and configure a terminal emulator, such as HyperTerminal or VT-100, using the display settings in Table 4 and
the connection settings in Table 5 (also, see the note following this procedure).
.
1
Your server or laptop configuration determines which COM port is used for Disk Array USB Port.
2
Verify the appropriate COM port for use with the CLI.
5. In the terminal emulator, connect to controller A.
6. Press Enter to display the CLI prompt (#).
The CLI displays the system version, MC version, and login prompt:
a. At the login prompt, enter the default user
manage .
b. Enter the default password
!manage .
If the default user or password—or both—have been changed for security reasons, enter the secure login credentials
instead of the defaults shown above.
7. At the prompt, type the following command to set the values you obtained in step 1 for each network port, first for
controller A and then for controller B:
set network-parameters ip address netmask netmask gateway gateway controller a|b
where:
 address is the IP address of the controller
 netmask is the subnet mask
 gateway is the IP address of the subnet router
 a|b specifies the controller whose network parameters you are setting
For example:
# set network-parameters ip 192.168.0.10 netmask 255.255.255.0 gateway 192.168.0.1 controller a
# set network-parameters ip 192.168.0.11 netmask 255.255.255.0 gateway 192.168.0.1 controller b
8. Type the following command to verify the new IP addresses:
show network-parameters
Network parameters, including the IP address, subnet mask, and gateway address are displayed for each controller.
9. Use the
ping command to verify network connectivity.
Table 4 Terminal emulator display settings
Parameter Value
Terminal emulation mode VT-100 or ANSI (for color support)
Font Terminal
Translations None
Columns 80
Table 5 Terminal emulator connection settings
Parameter Value
Connector COM3 (for example)
1,2
Baud rate 115,200
Data bits 8
Parity None
Stop bits 1
Flow control None

HP MSA 2050 Specifications

General

Model	HP MSA 2050
Category	Storage
Controller Type	Dual Controller
Form Factor	2U
Maximum Drives Supported	192
Cache Memory	8 GB per controller
Number of Controllers	2
Protocols	Fibre Channel, iSCSI, SAS
Drive Support	2.5-inch SFF and 3.5-inch LFF drives
Host Interfaces	16 Gb Fibre Channel, 10GbE iSCSI, 12 Gb SAS
RAID Levels Supported	RAID 0, 1, 5, 6, 10
Expansion Options	Supports expansion with MSA 2050 LFF and SFF Disk Enclosures
Power Supplies	Dual, redundant power supplies
Operating Temperature	10°C to 35°C (50°F to 95°F)
Warranty	3 years
Maximum Raw Capacity	192 TB
