HP MSR930 Series User Manual

32
Item 930 930G 931 931G 931DG
Memory 256 MB DDR III
Flash 128 MB
Dimensions (H
× W × D)
(excluding
rubber feet
and mounting
brackets)
43.6 × 230 × 160 mm (1.72 ×
9.06 × 6.30 in)
44.2 × 300 × 200 mm (1.74 × 11.81 × 7.84 in)
Weight
1.0 kg (2.20
lb)
1.1 kg (2.43 lb)
1.6 kg (3.53
lb)
1.6 kg (3.53
lb)
1.6 kg (3.53 lb)
AC power
adapter
Rated input voltage: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
Max. AC
power
24 W
Operating
temperature
0°C to 40°C (32°F to 104°F)
Relative
humidity (non-
condensing)
5% to 90%
Antenna specifications
Item S
p
ecification
Frequency range 806-960 MHz to 1710-2170 MHz
Voltage Standing Wave Ratio
(VSWR)
< 2.5
Input impedance 50 ohms
Gain 0 dBi
Max power consumption 25 W
Input interface TNC male
Length 254 mm (10 in)
Color Gray
Weight 45 g (1.59 oz)
Operating temperature –30°C to +70°C (–22°F to +158°F)

HP MSR930 Series Specifications

General

Brand	HP
Model	MSR930 Series
Category	Network Router
Language	English
