HP MSR930 Series - Appendix B: LED Status Indicators; Router Model LED Identification

34
Figure 36 Rear panel LEDs
(1) GE port status LED (yellow) (2) GE port status LED (green)
MSR931
Figure 37 Front panel LEDs
2
1
3
(1) System status LED (SYS) (2) Network status LED (INTERNET) (3) VPN status LED (VPN)
Figure 38 Rear panel LEDs
1
2
1 2
3
4
(1) GE port status LED (yellow) (2) GE port status LED (green)
(3) Serial port data receivin
g
status LED (ACT) (4) Serial port link status LED (LINK)
