Appendix B LEDs
LEDs
MSR930
Figure 33 Front panel LEDs
(1) System status LED (SYS) (2) Network status LED (INTERNET) (3) VPN status LED (VPN)
Figure 34 Rear panel LEDs
(1) GE port status LED (yellow) (2) GE port status LED (green)
MSR930G
Figure 35 Front panel LEDs
(1) System status LED (SYS) (2) Network status LED (INTERNET) (3) VPN status LED (VPN)
(3) 3G status LED (WWAN) (4) Received 3G si
g
nal stren
g
th indication LED (RSSI)
