5
Press the Select button to save your changes
and close the adjustment bar.
6
Press Exit to close the Moiré window.
Using the Status Window
The Status window is an information window that
displays the horizontal and vertical scan
frequencies, the resolution (for pre-set modes
only), and the serial number of the monitor.
To display the Status window:
1
In the OSD Advanced Menu window,
press the Plus (+) or Minus (–) button
to move to the Status icon.
2
Press the Select button to open the Status
window.
3
Press Select to close the Status window.
EXIT
SERIAL NUMBER
AASDD12345
FV :70Hz
FH :31KHz
RESOLUTION:
640 X 480
STATUS
EXIT
Restoring Factory Adjustments
To restore all parameters to the original factory
values:
1
Turn the power off.
2
While pressing the Plus (+) button, turn the
power back on.
