5–12 Maintenance and Service Guide
Removal and Replacement Procedures
5.6 Bluetooth Module
1. Prepare the computer for disassembly (refer to Section 5.3).
2. Loosen the Phillips PM2.0×5.0 screw 1 that secures the
Bluetooth module cover to the computer.
3. Remove the Bluetooth module cover 2.
Removing the Bluetooth Module Cover
Bluetooth Module Spare Part Number Information
Bluetooth module (includes Bluetooth module cable) 409993-001
