HP Nc6400 - Compaq Business Notebook Maintenance And Service Guide

E–2 Maintenance and Service Guide
Connector Pin Assignments
Table D-2
Audio-In (Microphone)
Pin Signal Pin Signal
1 Audio signal in 3 Ground
2 Audio signal in
Table D-3
Universal Serial Bus
Pin Signal Pin Signal
1 +5 VDC 3 Data +
2 Data – 4 Ground

HP Nc6400 - Compaq Business Notebook Specifications

General

Operating System	Windows XP Professional
Networking	10/100/1000 Gigabit Ethernet
Processor	Intel Core 2 Duo
RAM	Up to 4GB DDR2
Storage	80 GB HDD
Display	14.1-inch WXGA (1280 x 800)
Graphics	Intel GMA 950
Battery	6-cell Lithium Ion
Chipset	Intel 945GM Express
Optical Drive	DVD+/-RW
Wireless	Intel PRO/Wireless 3945ABG
Ports	3 USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Slots	ExpressCard/54
Dimensions	13.1 x 9.3 x 1.2 in
