Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery 0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
1 loosened to remove the
hard drive
4 to disassemble the
hard drive
5.5 Computer Feet 0
5.6 Bluetooth Module 1 loosened
5.7 External Memory Module 1 loosened to remove the
memory module
compartment cover
5.8 Mini Card WLAN Module 1 loosened to remove the
Mini Card module
compartment cover
2 removed to remove the
Mini Card WLAN module
Å
To prevent an unresponsive system and the display of a
warning message, install only a Mini Card device
authorized for use in your computer by the governmental
agency that regulates wireless devices in your country or
region. If you install a device and then receive a warning
message, remove the device to restore computer
functionality. Then contact technical support by selecting
Start > Help and Support > Contact support..
5.9 MultiBay II Device 1

HP Nc6400 - Compaq Business Notebook Specifications

General

Operating System	Windows XP Professional
Networking	10/100/1000 Gigabit Ethernet
Processor	Intel Core 2 Duo
RAM	Up to 4GB DDR2
Storage	80 GB HDD
Display	14.1-inch WXGA (1280 x 800)
Graphics	Intel GMA 950
Battery	6-cell Lithium Ion
Chipset	Intel 945GM Express
Optical Drive	DVD+/-RW
Wireless	Intel PRO/Wireless 3945ABG
Ports	3 USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Slots	ExpressCard/54
Dimensions	13.1 x 9.3 x 1.2 in
