HP Nc6400 - Compaq Business Notebook

Removal and Replacement Procedures
Maintenance and Service Guide 5–77
5.26 MultiBay II Eject Assembly
1. Prepare the computer for disassembly (Section 5.3),
and then remove the following components:
a. Hard drive (Section 5.4)
b. Bluetooth board (Section 5.6)
c. MultiBay II device (Section 5.9)
d. Keyboard (Section 5.10)
e. Switch cover (Section 5.15)
f. Fan assembly (Section 5.17)
g. Heat sink (Section 5.18)
h. Display assembly (Section 5.20)
i. Top cover (Section 5.21)
j. PC Card/digital media board (Section 5.22)
k. Speaker (Section 5.23)
l. Microphone (Section 5.24)
m. System board (Section 5.25)
MultiBay II Eject Assembly
Spare Part Number Information
MultiBay II eject assembly 418905-001
