HP Nc6400 - Compaq Business Notebook

5–78 Maintenance and Service Guide
Removal and Replacement Procedures
2. Remove the Phillips PM2.0×6.0 screw 1 that secures the
MultiBay II eject assembly to the base enclosure.
3. Remove the MultiBay II eject assembly 2 from the base
enclosure.
Removing the MultiBay II Eject Assembly
Reverse the above procedure to install the MultiBay II eject
assembly.
