5ā76 Maintenance and Service Guide
Removal and Replacement Procedures
14. If it is necessary to replace the modem connector and cable,
remove the connector 1 from the clip in the base enclosure
and remove the cable 2 from the routing channel in the base
enclosure.
ā
The modem cable is available in the Cable Kit, spare part
number 418876-001.
Removing the Modem Connector and Cable
Reverse the above procedures to install the system board.
