Removal and Replacement Procedures
Maintenance and Service Guide 5–15
3. Loosen the Phillips PM2.0×5.0 screw 1 that secures the
memory module compartment cover to the computer.
4. Lift the right edge of the cover 2 and swing it up and to the
left.
5. Remove the memory module compartment cover.
✎
The memory module compartment cover is included in the
Plastics Kit, spare part number 418877-001.
Removing the Memory Module Compartment Cover
