Removal and Replacement Procedures
Maintenance and Service Guide 5–19
1. Prepare the computer for disassembly (Section 5.3).
2. Position the computer with the front toward you.
3. Loosen the Phillips PM2.0×5.0 screw 1 that secures the
Mini Card module compartment cover to the computer.
4. Lift the front of the cover 2 and swing it up and toward
the back of the computer.
5. Remove the Mini Card module compartment cover.
✎
The Mini Card module compartment cover is included in the
Plastics Kit, spare part number 418877-001.
Removing the Mini Card Module Compartment Cover
