Removal and Replacement Procedures
Maintenance and Service Guide 5ā27
11. If it is necessary to replace the pointing stick cable, turn the
keyboard upside down with the space bar toward you.
12. Release the ZIF connector 1 to which the pointing stick
cable is attached and disconnect the pointing stick cable 2.
ā
The pointing stick cable is included with all keyboard spare
part kits and is also available in the Cable Kit, spare part
number 418876-001.
Removing the Pointing Stick Cable
Reverse the above procedure to install the keyboard.
