HP Nc6400 - Compaq Business Notebook

Removal and Replacement Procedures
Maintenance and Service Guide 5–67
2. Disconnect the microphone cable 1 from the system board.
3. Remove the microphone 2 from the base enclosure.
Removing the Microphone
Reverse the above procedure to install the microphone.
