Specifications
Maintenance and Service Guide 6–3
Table 6-2
14.1-inch, WXGA
Dimensions
Height
Width
Diagonal
21.3 cm
28.5 cm
35.8 cm
8.4 in
11.2in
14.1 in
Number of colors Up to 16.8 million
Contrast ratio 250:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.279 × 0.279 mm
1024 × 768
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4.0 W
Viewing angle +/-40° horizontal, +120/-40° vertical
typical
