HP Nc6400 - Compaq Business Notebook

Screw Listing
Maintenance and Service Guide A–21
Torx8 T8M2.5×7.0 Screw Locations
Table A-13
Torx8 T8M2.5×7.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 8 7.0 mm 2.5 mm 5.0 mm
Where used:
2 screws that secure the display assembly to the computer (documented in
Section 5.20)
mm
