HP Nc6400 - Compaq Business Notebook Maintenance And Service Guide

Screw Listing
Maintenance and Service Guide A–23
Torx8 T8M2.5×7.0 Screw Location
Table A-13
Torx8 T8M2.5×7.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 8 7.0 mm 2.5 mm 5.0 mm
Where used:
One screw that secures the top cover to the computer (documented in
Section 5.21)
mm

HP Nc6400 - Compaq Business Notebook Specifications

General

Operating System	Windows XP Professional
Networking	10/100/1000 Gigabit Ethernet
Processor	Intel Core 2 Duo
RAM	Up to 4GB DDR2
Storage	80 GB HDD
Display	14.1-inch WXGA (1280 x 800)
Graphics	Intel GMA 950
Battery	6-cell Lithium Ion
Chipset	Intel 945GM Express
Optical Drive	DVD+/-RW
Wireless	Intel PRO/Wireless 3945ABG
Ports	3 USB 2.0, VGA, headphone, microphone, RJ-11, RJ-45
Slots	ExpressCard/54
Dimensions	13.1 x 9.3 x 1.2 in
