Removing the monitor feet
CAUTION: Before beginning to disassemble the monitor, be sure that the monitor is turned o and all cables
are disconnected.
1. Disconnect and remove all cables from the monitor.
2. Position the monitor head face up on a at surface covered by a clean, dry cloth.
3. Remove the screws from the feet (1) and detach the feet from the monitor (2).
Attaching the monitor head to a mounting device
1. Remove the monitor feet. See Removing the monitor feet on page 9.
2. Locate the 400 mm x 400 mm VESA mounting holes on the back of the monitor. Then follow the
instructions included with your mounting device.
IMPORTANT: Follow the mounting device manufacturer’s instructions when mounting the monitor to a
wall or swing arm.
Setting up the monitor 9
