HP P22 G5 User Manual

22
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare Part number
Manufacturer Part number
25W for P22/P22h/P24/P24h N17097-001 R352000120157
35W for P27h N17098-001 R352000220157
160W for P32u
N17099-001
N17099-002
050005180010
050005070070
Capacitors and connectors are available for purchase from the following EU distributors:
Farnell: Farnell UK - Electronic Components Distributor
RS Component: Capacitors | RS Components (rs-online.com)
Digi-Key Component: Digi-Key Component United Kingdom
Capacitors by distributor (P27h G5)
Component description
Location
Component distributor
Distributor part number
470uF 25V 105'C (10x12mm) C202, C203 Digi-Key EV1E471MP51012U
Capacitors by distributor (P32u G5)
Component description
Location
Component distributor
Distributor part number
820u_25V_105°C_Ø 10x16 for SanHua
E200C,E201C.
E202C.E203C
Digi-Key RF1E821MP51016EU
680u_25V_105°C Ø 10x14 for DELTA C112.C113 Digi-Key 25ZL680MEFCT810X20
470u_25V_105°C Ø 10x14 for DELTA C111.C115 Digi-Key 25ZLH470MEFCT810X12.5
Connectors by manufacturer (P22 G5/P24 G5/P22h G5, P24h G5, P27h G5)
Component description
Location
Component distributor
Distributor part number
DisplayPort P300 Farnell 10090926-P154VLF
HDMI P200 Farnell RAHHD19TR
VGA P100 Farnell DP1RD20JQ1

HP P22 G5 Specifications

General

Color gamut	72 %
Pixel pitch	0.25 x 0.25 mm
Screen shape	Flat
Display diagonal	21.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Contrast ratio (dynamic)	8000000:1
Display number of colors	16.7 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HP segment	Business
Product color	Black
HDMI version	1.4
DisplayPort version	1.2
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	25 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Cables included	AC, HDMI
Package depth	121 mm
Package width	567 mm
Package height	387 mm
Package weight	5240 g

Weight and Dimensions

Depth (with stand)	180.5 mm
Width (with stand)	488.4 mm
Height (with stand)	378.2 mm
Weight (with stand)	3250 g
Depth (without stand)	51.2 mm
Height (without stand)	294.3 mm
