HP P22 G5 User Manual

5
Front components
To identify the components on the front of the monitor, use this illustration and table.
P22 G5/ P24 G5 P22h G5/ P24h G5/ P27h G5
Table 1-1: Front components and their descriptions
Component
Function
1 Power button
T
urns the monitor on or off.
2 Power light
W
hite: The monitor is on.
Amber: Monitor is in a reduced power state
because of inactivity.
NOTE: You can reconfigure the Function buttons in the OSD menu to quickly select the most commonly
used operations. Press the Menu button to open the OSD, and then select Menu Control. Select
Assign buttons, and then select one of the available options for the button you want to assign.

HP P22 G5 Specifications

General

Color gamut	72 %
Pixel pitch	0.25 x 0.25 mm
Screen shape	Flat
Display diagonal	21.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Contrast ratio (dynamic)	8000000:1
Display number of colors	16.7 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HP segment	Business
Product color	Black
HDMI version	1.4
DisplayPort version	1.2
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	25 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Cables included	AC, HDMI
Package depth	121 mm
Package width	567 mm
Package height	387 mm
Package weight	5240 g

Weight and Dimensions

Depth (with stand)	180.5 mm
Width (with stand)	488.4 mm
Height (with stand)	378.2 mm
Weight (with stand)	3250 g
Depth (without stand)	51.2 mm
Height (without stand)	294.3 mm
