▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 24.
Remove the Rear Cover:
For P22 G5/P22h G5/P24 G5/P24h G5
1. Lay the display on soft desk, Twist out the screw and separate base and stand.
2. Then pull out the stand form the monitor head.
3. Remove the 6 screws from the back cover and use tools to open the back cover.
4. Remove the 8pin FFC from main board then remove rear cover
Twist out
To Next Page
