Power Board
The power board part number
25W for P22/P22h/P24/P24h N17097-001 R352000120157
35W for P27h N17098-001 R352000220157
160W for P32u
N17099-001
N17099-002
050005180010
050005070070
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 24.
Remove the power board:
The power board connector position is as follows, part number on back side
Fr
ont side Back side
25W
E/C EV
MOSFET
Fuse
To Next Page
