Front components

To identify the components on the front of the monitor, use this illustration and table.

Table 1-2 Front components

Control

Function

Menu button

Press to open the OSD menu, select a menu item from the OSD, or close the OSD

menu. When the OSD menu is open, the Menu light turns on.

OSD buttons

(assignable)

When the OSD menu is open, press the buttons to navigate through the menu.

The function light icons indicate the default button functions. For a description of

these functions, see Using the function buttons on page 15

You can reassign the function buttons to quickly select the most commonly

used operations. See Reassigning the function buttons on page 15.

Power button

Turns the monitor on or off.

Other manuals for HP P27q G4

Questions and Answers:

Need help?

Do you have a question about the HP P27q G4 and is the answer not in the manual?

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	0.233 x 0.233 mm
Screen shape	Flat
Pixel density	109 ppi
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Display number of colors	-
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Product color	Black
Market positioning	Business
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
HDMI version	1.4
AC input voltage	100 - 240 V
Power consumption (max)	36 W
Power consumption (standby)	0.5 W
Power consumption (typical)	32 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package weight	4630 g
Harmonized System (HS) code	85285210
