HP PAVILION DV2500 Maintenance And Service Guide

Metric U.S.
Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this
range of temperatures.
14.1-inch, WXGA, BrightView display specifications
Metric U.S.
Dimensions
Height 27.94 cm 11.0 in
Width 20.83 cm 8.2 in
Diagonal 35.56 cm 14.1 in
Number of colors
Up to 16.8 million
Contrast ratio
250:1 (typical)
Brightness
180 nits (typical)
Pixel resolution
Pitch 0.279 × 0.279 mm
Format 1280 × 800
Configuration RGB vertical stripe
Backlight
Edge lit
Character display
80 × 25
Total power consumption
4 W
Viewing angle
+/-40° horizontal, +20/-40° vertical (typical)
106 Chapter 6 Specifications

HP PAVILION DV2500 Specifications

General

CPU	Intel Core 2 Duo
Screen Resolution	1280 x 800
Memory	Up to 4GB DDR2
Display	14.1-inch WXGA
Hard Drive	Up to 250GB SATA
Optical Drive	DVD±RW
Wireless	802.11b/g
Operating System	Windows Vista
