HP PAVILION DV2500 Maintenance And Service Guide

Display assembly
Description Spare part number
14.1-inch, WXGA, BrightView, display assembly for use only with computer models equipped with a
camera module (includes camera module, microphones, and WLAN transceivers and antenna cables)
448604-001
14.1-inch, WXGA, BrightView, display assembly for use only with computer models not equipped
with a camera module (includes microphones and WLAN transceivers and antenna cables)
448603-001
14.1-inch, WXGA, BrightView, display assembly for use only with computer models sold at Best Buy
(includes camera module, microphones, and WLAN transceivers and antenna cables)
451906-001
Before removing the display assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 47).
5.
Disconnect the wireless antenna cables from the WLAN module (see
WLAN module on page 55).
6.
Remove the following components:
a.
Keyboard (see
Keyboard on page 63)
b.
Switch cover (see
Switch cover on page 65)
Remove the display assembly:
1.
Close the computer and turn it upside down, with the rear panel toward you.
2.
Remove the Phillips PM2.5×9.0 screw that secures the display assembly to the computer.
3.
Turn the computer display-side up, with the front toward you.
68 Chapter 4 Removal and replacement procedures

HP PAVILION DV2500 Specifications

General

CPU	Intel Core 2 Duo
Screen Resolution	1280 x 800
Memory	Up to 4GB DDR2
Display	14.1-inch WXGA
Hard Drive	Up to 250GB SATA
Optical Drive	DVD±RW
Wireless	802.11b/g
Operating System	Windows Vista
