HP PAVILION DV2500 Maintenance And Service Guide

Phillips PM2.0×5.0 captive screw
Color Quantity Length Thread Head diameter
Black 5 5.0 mm 2.0 mm 5.0 mm
Where used:
(1) Two captive screws (secured by C-clips) that secure the hard drive cover to the computer
(2) Two captive screws (secured by C-clips) that secure the memory module compartment cover to the
computer
(3) One captive screw (secured by a C-clip) that secures the wireless module compartment cover to the
computer
120 Chapter 7 Screw listing

HP PAVILION DV2500 Specifications

General

CPU	Intel Core 2 Duo
Screen Resolution	1280 x 800
Memory	Up to 4GB DDR2
Display	14.1-inch WXGA
Hard Drive	Up to 250GB SATA
Optical Drive	DVD±RW
Wireless	802.11b/g
Operating System	Windows Vista
