Phillips PM2.5×9.0 screw
Color Quantity Length Thread Head diameter
Black 15 9.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) Three screws that secure the switch cover to the computer
(3) One screw that secures the display assembly to the computer
126 Chapter 7 Screw listing
