HP PAVILION DV2500 Maintenance And Service Guide

4. Use the media tray frame to remove the optical drive (3).
5.
If it is necessary to replace the optical drive bracket, position the optical drive with the optical drive
bracket toward you.
6. Remove the two Phillips PM2.0×3.0 screws (1) that secure the optical drive bracket to the optical
drive.
7. Remove the optical drive bracket (2).
Reverse the above procedure to reassemble and install the optical drive.
Keyboard
Countries or regions Spare part number Countries or regions Spare part number
Belgium 448615-021 Portugal 448615-131
Brazil 448615-201 Russia 448615-251
Canadian French 448615-121 Saudi Arabia 448615-171
Denmark, Finland, Norway, and
Sweden
448615-DH1 South Korea 448615-AD1
Component replacement procedures 63

HP PAVILION DV2500 Specifications

General

CPU	Intel Core 2 Duo
Screen Resolution	1280 x 800
Memory	Up to 4GB DDR2
Display	14.1-inch WXGA
Hard Drive	Up to 250GB SATA
Optical Drive	DVD±RW
Wireless	802.11b/g
Operating System	Windows Vista
