HP PAVILION DV2500 Maintenance And Service Guide

4. Remove the audio board (4).
Reverse the above procedure to install the audio board.
Bluetooth module
Description Spare part number
Bluetooth module (includes Bluetooth module cable) 397923-002
Before removing the Bluetooth module, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 47).
5.
Remove the following components:
a.
Hard drive (see
Hard drive on page 52)
b.
WLAN cover (see
WLAN module on page 55)
c.
Optical drive (see
Optical drive on page 62)
d.
Keyboard (see
Keyboard on page 63)
e.
Switch cover (see
Switch cover on page 65)
f.
Display assembly (see
Display assembly on page 68)
g.
Top cover (see
Top cover on page 73)
h.
Audio board (see
Audio board on page 82)
Component replacement procedures 83

HP PAVILION DV2500 Specifications

General

CPU	Intel Core 2 Duo
Screen Resolution	1280 x 800
Memory	Up to 4GB DDR2
Display	14.1-inch WXGA
Hard Drive	Up to 250GB SATA
Optical Drive	DVD±RW
Wireless	802.11b/g
Operating System	Windows Vista
