3. Remove the power connector (1) from the connector frame.
4. Remove the modem connector (2) from the connector frame.
Reverse this procedure to install the power connector cable and modem cable.
ExpressCard assembly
Description Spare part number
ExpressCard assembly 417112-001
Before removing the ExpressCard assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 47).
5.
Remove the following components:
a.
Hard drive (see
Hard drive on page 52)
b.
Optical drive (see
Optical drive on page 62)
c.
Keyboard (see
Keyboard on page 63)
d.
Switch cover (see
Switch cover on page 65)
e.
Display assembly (see
Display assembly on page 68)
f.
Top cover (see
Top cover on page 73)
g.
System board (see
System board on page 91)
94 Chapter 4 Removal and replacement procedures
